| 무게: | 29kg | 재료: | 탄소강 |
|---|---|---|---|
| 처리 유형: | 단조 | 크기: | 3 인치 |
| 외경: | 81 밀리미터 | 길이: | 1063 mm |
| 버튼 모양: | 탄도/세미 볼리즘/구형 | 정꼬리: | SRC531 |
| 구멍 범위: | φ84-φ100 | 연결 스레드: | 3" 리메트 |
| 작동 압력: | 1.0MPa-3.0MPa | 공기 소비: | 7 m³/min @ 1.7 MPa |
| 공기 소비: | 10 m³/min @ 2.4 MPa | 공기 소비: | 14 m³/min @ 3.0 MPa |
| 길이 (비트가 적음): | 1069 밀리미터 | ||
| 강조하다: | SRC531 RC Hammer,3inch Reverse Circulation Hammer,81mm Down The Hole Hammer |
||
Reverse circulation drilling efficiently collects samples by transporting them through hollow pipes, preventing contamination from surface materials. This method is particularly valuable for maintaining sample integrity in mining and well drilling applications.
| Length (less bit) | 1069mm |
| Weight (less bit) | 29.0kg |
| External diameter | φ81mm |
| Bit shank | SRC531 |
| Hole range | φ84-φ100 |
| Connection thread | 3" Remet |
| Working pressure | 1.0Mpa-3.0Mpa |
| Air consumption (1.7 Mpa) | 7 m³/min |
| Air consumption (2.4 Mpa) | 10 m³/min |
| Air consumption (3.0 Mpa) | 14 m³/min |
Standard delivery time: 15-25 days. Express delivery (3-5 days) available when items are in stock.
Shipping options: By Air, By Sea, or By express.
Packaging: Ply-wooden cases with pallet.
