| 지름: | 110mm | 무게: | 10kg |
|---|---|---|---|
| 재료: | 침탄강 | 처리 유형: | 단조 |
| 얼굴 모양: | 평면, 볼록, 오목 | 버튼 유형: | 구형, 포물선, 탄도 |
| 비트 Dia: | 105, 110, 115, 120, 125, 130mm | 공기 호스: | 2 |
| 게이지 버튼: | 6×Φ14, 7×Φ14, 8×Φ14 | 전면 버튼: | 5×Ø13, 6×Ø13, 7×Ø13, 7×Ø14 |
| 부품 번호: | HD45-105, HD45-110, HD45-115, HD45-120, HD45-125, HD45-130 | 암석 경도: | 200-260 MPa |
| 생크 유형: | SD4 | 비트 직경(인치): | 4 1/8", 4 5/16", 4 1/2", 4 3/4", 4 15/16", 5 1/8" |
| 인서트 타입: | 텅스텐 카바이드 | ||
| 강조하다: | Carburized Steel DTH Drill Bits,Flat Face DTH Drill Bits,Convex Face DTH Drill Bits |
||
DTH hammers and bits are widely used in underground mining, quarries, hydraulic and hydro-power engineering, water well drilling, mineral exploration, anchoring hole drilling, geothermal engineering, subway excavation, and other civil engineering projects.
Key advantages include high flatness, smooth hole walls, rigid drill rod and hammer construction, independent of high axial thrust, unlimited drilling depth capability, low device costs, and easy maintenance.
| 4" Shank Bits | Bit Dia (mm) | Bit Dia (inch) | Air Hose | Gauge Buttons | Front Buttons | Part No |
|---|---|---|---|---|---|---|
| SD4 | 105 | 4 1/8" | 2 | 6×φ14 | 5×φ13 | HD45-105 |
| SD4 | 110 | 4 5/16" | 2 | 7×φ14 | 6×φ13 | HD45-110 |
| SD4 | 115 | 4 1/2" | 2 | 7×φ14 | 7×φ13 | HD45-115 |
| SD4 | 120 | 4 3/4" | 2 | 8×φ14 | 7×φ13 | HD45-120 |
| SD4 | 125 | 4 15/16" | 2 | 8×φ14 | 7×φ13 | HD45-125 |
| SD4 | 130 | 5 1/8" | 2 | 8×φ14 | 7×φ14 | HD45-130 |
Delivery options: By sea, by air, or by express shipping.
