| 지름: | 90-105mm | 무게: | 4.4 KG |
|---|---|---|---|
| 재료: | 침탄강 | 처리 유형: | 열처리 및 가공 공정 |
| 비트 직경: | 95mm | 플러싱 홀: | 2*14 |
| 게이지 버튼: | 6*14 | 전면 버튼: | 4*13 |
| 버튼 직경: | 14mm, 13mm | 얼굴 디자인: | 편평한 얼굴 또는 오목한 |
| 공기 압축기: | 높은 기압 | 기계 유형: | 드릴링 도구 |
| 유형: | 드릴 비트 | 체중(kg): | 4.7 |
| 거꾸로 된 조종사: | 예 | ||
| 강조하다: | 3''-95mm DTH Drill Bit,Heat Treatment DTH Drill Bit,Flat Face Design DTH Drill Bit |
||
For applications involving drilling through various rock types with fractures or fissures, the flat face design delivers optimal results. The flat face effectively handles ledges and resists getting stuck or pinched in the formation.
The concave face design is ideal for deep holes or when directional control is critical. This design helps maintain vertical alignment and improves borehole directional control, preventing deviation along geological weak points.
| Bit Diameter | Flushing Holes | No.*Button Dia.mm | Weight (Kg) |
|---|---|---|---|
| 95 mm | 3 3/4" | Gauge Buttons | 2 * 14 | 4.7 |
| Front Buttons | 6*14 | 4*13 |
Shipping: By Air, By Sea, or By Express
Package: Ply-wooden cases + Pallet
